Description
Technical Parameters
● Operating Temperature:
○ Standard Bonnet: -29°C ~ 180°C
○ Low Temperature Bonnet: -46°C ~ 180°C
○ Cryogenic Bonnet: -196°C ~ 180°C
● Body & Bonnet Material: WCB / Cf8
● Plug Material: 304 / 316L
● Plug & Seat Material: 304 / 316L / 17-4PH
● Lining Material: D46 / PFA
● Sealing Type: Soft Seal
● Leakage Class: Class IV, Class V, Class VI
● Flow Characteristics: Equal Percentage, Linear, Quick Opening, Segmented
● Packing Type: PTFE V-Ring
● Surface Treatment: Painting
