Technical Parameters
Operating Temperature:
○ Standard Bonnet: -29℃ ~ 230℃
○ High Temperature Bonnet: -29℃ ~ 530℃
○ Low Temperature Bonnet: -46℃ ~ 230℃
○ Cryogenic Bonnet: -196℃ ~ 180℃
○ Bellows Seal Bonnet: -101℃ ~ 530℃
● Body & Bonnet Materials: LCB / WCB / CF8 / CF8M / CF3M / Hastelloy / Monel / Duplex Stainless Steel
/ High Temperature Alloy Steel, etc.
● Plug & Seat Materials: 304 / 316L / 410 / 630 / Hastelloy / Monel
● Sealing Type: Hard Seal, Soft Seal
● Leakage Class: Class IV, Class V, Class VI
● Flow Characteristics: Equal Percentage, Linear, Quick Opening, Segmented
● Packing Type: PTFE V-Ring, Flexible Graphite, PTFE + Graphite Composite Packing, Low-Leakage Packing,
Vacuum Packing
● Surface Treatment: Phosphating / Shot Blasting / Painting
